  • 2-1/2" Utility Pressure Gauge for water, oil, gas (WOG) - Black Steel 1/4" NPT Lower Mount

2-1/2" Utility Pressure Gauge for water, oil, gas (WOG) - Black Steel 1/4" NPT Lower Mount

SKU: PA254L

Manufacturer: DuraChoice

1 Review

2-1/2" Dry Utility Pressure Gauge - Black Steel with a 1/4" NPT Lower Mount Connection


Dial Size: 1-1/2", 2" or 2-1/2" Dial Sizes (Crimped Casing)
Accuracy: +/- 4/3/4 %
Scale: Dual Scale - PSI / Bar
Movement: Copper Alloy*
Bourdon Tube: Copper Alloy*
Window: Glass
Case: Steel case for protection in harsh environments
Connection: Copper Alloy Lower Mount*; 1/8" NPT (for 1-1/2" dial) and 1/4" NPT (for 2" and 2-1/2" dials)
Normal Ambient Temp: -4F to +140F (-20C to +60C)


Please Note: Brass components in this product contain lead, known to the State of California to cause cancer and birth defects or other reproductive harm. California law requires that this warning be given to consumers.

2-1/2" Utility Pressure Gauge for water, oil, gas (WOG) - Black Steel 1/4" NPT Lower Mount

Manufacturer: DuraChoice

  • PA254L-015 2-1/2" Utility Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, 0-15PSI
  • PA254L-030 2-1/2" Utility Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, 0-30 PSI
  • PA254L-060 2-1/2" Utility Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, 0-60PSI
  • PA254L-100 2-1/2" Utility Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, 0-100PSI
  • PA254L-160 2-1/2" Utility Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, 0-160PSI
  • PA254L-200 2-1/2" Utility Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, 0-200PSI
  • PA254L-300 2-1/2" Utility Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, 0-300PSI
  • PA254L-500 2-1/2" Utility Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, 0-500PSI
  • PA254L-600 2-1/2" Utility Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, 0-600PSI
  • PA254L-K01 2-1/2" Utility Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, 0-1,000PSI
  • PA254L-K015 2-1/2" Utility Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, 0-1500PSI
  • PA254L-K02 2-1/2" Utility Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, 0-2,000PSI
  • PA254L-K03 2-1/2" Utility Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, 0-3,000PSI
  • PA254L-K04 2-1/2" Utility Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, 0-4,000PSI Low Stock - Chat or Call to check
  • PA254L-K05 2-1/2" Utility Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, 0-5,000PSI
  • PA254L-K06 2-1/2" Utility Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, 0-6,000PSI
  • PA254L-V00 2-1/2" Utility Vaccum Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, -30HG/0PSI
  • PA254L-V30 2-1/2" Utility Vaccum Pressure Gauge for Water, Oil, Gas, 1/4" NPT Lower Mount, Black Steel Case, -30HG/30PSI
Items:0  |  Total:$0.00

DESCRIPTION

DuraChoice Lower Mount Dry Utility Pressure Gauges are some of the best in the business. Wrapped in black steel with a glass window, DuraChoice pressure gauges are made to withstand tough environments. These gauges are available in pressure ranges from vacuum to 6,000 PSI.

The gauges are made for use with water, oil, gas (WOG) and diesel.


Dial Size:2-1/2" Dial Size (Crimped Casing)
Accuracy:+/- 4/3/4%
Scale:Dual Scale - PSI / Bar
Movement:Copper Alloy
Bourdon Tube:Copper Alloy
Window:Glass
Case:Steel case for protection in harsh environments
Connection:Copper Alloy Lower Mount; 1/4" NPT (for 2-1/2" dial)
Normal Ambient Temp.:-30F to +140F (-34C to +60C)


Please Note: Brass components in this product contain lead, known to the State of California to cause cancer and birth defects or other reproductive harm. California law requires that this warning be given to consumers.

California Prop 65 Warning: Brass components in this product contain lead, known to the state of California to cause cancer and birth defects or other reproductive harm. California law requires that this warning be given to consumers
